DLE40
Powerful Performance, Professional Grade. Engineered for High-End Flight Applications.
Technical Specs
Detailed performance metrics of DLE40
Core Performance
- Performance
- 4.8HP/8500rpm
- Idle Speed
- 1500 RPM
- Thrust (100m altitude)
- 9.5kg
- Thrust (1800m altitude)
- 8.5kg
- Propeller Specs
- 19x8 ; 19x10 ; 20x8 ; 20x10
- Spark Plug Type
- NGK CM6
Specs & Weight
- Displacement
- 40cm³
- Bore × Stroke
- 32mm × 25mm
- Compression Ratio
- 10.5 : 1
- Lubrication Ratio
- 30 : 1
- Weight Distribution
- Engine 1170gMuffler 110gIgnition 170g
- Ignition Voltage
- 4.8V - 8.4V
Product Dimensions
Precise engineering dimension drawings for your cabin layout planning.
Technical Downloads
Get detailed installation instructions and 3D model data for DLE40 to help you complete deployment quickly.
